Name : King Kong(simple) 16 Led Display Technical Specification
Best view distance : ≥48m
Model : SBC-J-G-P16
Mark : SBC
Origin : shenzhen
Lead Time : 25days
Warranty : one years
Certificates : CE,RoHS,Fcc
Browse :
Kingkong(simple)16 LED display is special made for application of giant outdoor advertising screen. Use synchronous system which can accept signals DVI, VGA,HDMI,S-VIDEO,Complex, YUV etc. It can display programs of video, image, text. Displaying every information by real time, synchronous,clear message and can show two or three dimension animation, video, TV, VCD program and live broadcast. King Kong(simple) 16 Led Display Technical Specification Product Name£ºLED Display Product type£ºKing Kong (simple) 16 Manufacturer£ºShenzhen SBC Photoelectricity co.,ltd. Technical Specification Requirements Type Technical requirements Best view distance(m) ≥48m Pixel pitch (m) 16mm Pixel resolution(Dots/m2) 3906dots/m2 Pixel color composition 1R1G1B (DIP346) Cabinet size 1024*768*120mm Cabinet weight 46KG Scan method(s) 1/2S Brightness(cd/m2 ) ≥3500cd/m2 adjustable by software Refresh frequency (Hz) ≥1000Hz adjustable by software MTBF(H) >10000H Max. power consumption(W/m2) 500W/ m2 Ave. Power consumption(W/m2) 200W/ m2 View angle 120 °horizontally, 120°vertically Grey level/Color 16.7M colors(Synchronized) Color temperature R.G.B brightness 256 level adjustable, Color temperature is adjustable according to your requirement. IP level IP65 Defects rate <1/10000Dots Life span(H) >100000H Operation voltage AC220V±10%/AC110V±10%(Power can¡¯t be converted directly) Operating temperature -20℃~+60℃ Operating humidity 10%RH~90%RH Storage temperature -10℃~+50℃ System Operating Platform WIN 98/ 2000/ XP Control PC With DVI Graphic card ( brand PC recommended) Video signal RF/S-Video/RGB/RGBHV/YUV/YC/etc Effective control distance without repeater Unshielded Twisted-pair LAN cable transmission within 100m Multi-mode optical fiber¨Q500m,mono-mode optical fiber¨Q20km. További kültéri kijelzők
As a new advertising screen, the screen will be designed stably, sturdy, durable, easy for outdoor big size advertising usage.
Features of Kingkong(easy cabinet)16
1.Use DIP technology to make the LED display have good waterproof and anti-humidity when used.
2.Stable cabinet, stronger without distortion, anti-rust.
3.Synchronously adjust the brightness and color to make the true and exquisite image.
4.High contrast, high refresh rate make the image without any delay, trailing smear.
5.Compatible to many signal sources such as AV, S-Video, DVI, VGA, YPbPr, HDMI,SDI,DP etc.
6.pecial wooden box package production protect the whole screen system.
7.Patent mask design, advanced encapsulation equipments, high quality material make the cabinet more stable and stronger.
