KingKong 20 One Side Front Open LED display is special made for application of giant outdoor advertising screen. Use synchronous system which can accept signals DVI, VGA,HDMI,S-VIDEO,Complex, YUV etc. It can display programs of video, image, text. Displaying every information by real time, synchronous,clear message and can show two or three dimension animation, video, TV, VCD program and live broadcast.
As a new advertising screen, the screen will be designed stably, sturdy, durable, easy for outdoor big size advertising usage.
Features of KingKong 20 One Side Front Open
1.Use DIP technology to make the LED display have good waterproof and anti-humidity when used.
2.Stable cabinet, stronger without distortion, anti-rust.
3.Synchronously adjust the brightness and color to make the true and exquisite image.
4.High contrast, high refresh rate make the image without any delay, trailing smear.
5.Compatible to many signal sources such as AV, S-Video, DVI, VGA, YPbPr, HDMI,SDI,DP etc.
6.Special wooden box package production protect the whole screen system.
7.Perfect design with cutting-edge technology, has simple appearance, compact structure, stable features and excellent color expression.
|
Technical Specification Requirements |
|
|
Type |
Technical requirements |
|
Best view distance(m) |
60m |
|
Pixel pitch(m) |
20mm |
|
Pixel resolution(Dots/㎡) |
10000Dots/㎡ |
|
Pixel color composition |
1R1G1B（DIP346） |
|
Cabinet size |
1920*1200*225mm |
|
Cabinet weight |
150KG |
|
Scan method（S） |
Static |
|
Brightness（cd/㎡） |
≥8000cd/m2 adjustable by software |
|
Refresh frequency(Hz) |
≥1000Hz adjustable by software |
|
MTBF（H） |
>10000H |
|
Max. power consumption（W/㎡） |
1000W/ m2 |
|
Ave. Power consumption（W/㎡） |
800W/ m2 |
|
View angle |
140° |
|
Grey level/Color |
16.7Mcolors（Synchronized） |
|
Color temperature |
R.G.B brightness 256 level adjustable, Color temperature is adjustable according to your requirement. |
|
IPlevel |
IP65 |
|
Defects rate |
＜1/10000Dots |
|
Life span（H） |
＞100000H |
|
Operation voltage |
AC220V±10％/AC110V±10％（Power can’t be converted directly） |
|
Operating temperature |
-20℃～+60℃ |
|
Operating humidity |
10%RH~90%RH |
|
Storage temperature |
-10℃～+50℃ |
|
System Operating Platform |
WIN 98/ 2000/ XP |
|
Control PC |
With DVI Graphic card ( brand PC recommended) |
|
Video signal |
RF、S-Video、RGB、RGBHV、YUV、YC etc |
|
Effective control distance without repeater |
Unshielded Twisted-pair LAN cable transmission within 100m |
|
Multi-mode optical fiber≦500m,mono-mode optical fiber≦20km. |
|
|
