LED kijelző gridding alkalmas  épület mögötti telepítésre (üveg fal).

Gridding LEDFAL  közepén üreges, áttetsző, az alap nem befolyásolja a természetes fény utját az épületen belül.

Paraméterek:

Pixel pitch                            37.5mm

Unit panel size                     600mm x 600mm

Pixel density                        711dot / m²

Brightness                            4000 CD / m²

LED Encapsulation                DIP

Horizontal view angle          > 140°

Vertical view angle              > 120°

Life                                       100000 hours

Average power                    300 W / m²

Weight / Module                  8 kg

Display colors                      4.4 trillion colors

Refresh rate                         3000Hz / S

Driving mode                       Static

Working temperature         -20°----  +45°C

Input signal                         Data DVI up to UXGA, SDI, HD-SDI, S-video, composite, YUV

Failed LED rate                     <0.0001

Quality certification             ETL, CE, TUV, FCC class A

Referencia:

Dongguan Jia Yi Real Estate Development Co., Ltd. outdoor full color grid LED display project

Project Location: Guangdong Dongguan Jia Yi Garden
Product Specifications: SG129W
Item Size: length 90m * Height 27m = 2430 sqm
Screen Body Quantity: 1 pc
Completion Time: March 18, 2009
